Mac 200 Double Head Tube Filling Machine

The Mac 200 handles laminated tubes, plastic tubes, and aluminium tubes depending on the closing configuration. The Hot Air (HA) configuration seals laminated and plastic tubes up to 50 mm diameter. The Metal (AL) configuration handles aluminium fold-and-crimp tubes up to 40 mm diameter. The Combination model supports both tube materials on one machine for flexible production planning.

The Mac 200 has two filling heads compared to the single head of the Mac 100, delivering up to 150 tubes per minute versus 75–100. Both share the same servo-driven dosing, timing belt transport, and tool-free changeover architecture. The Mac 200 is the right choice when output demand has outgrown a single-head platform without wanting to double the machine footprint.

The dual servo pumps on the Mac 200 handle fill volumes from 2 ml up to 300 ml. Each head has an independently calibrated servo pump, so both heads dispense the same validated fill weight simultaneously. This works equally well for low-viscosity fluids and high-viscosity stiff pastes such as ointments, toothpaste, and pharmaceutical creams without product waste between cycles.

No — both heads are fed from the same product hopper and fill simultaneously with the same formulation. This ensures consistent output at maximum speed and eliminates any risk of cross-contamination between positions. If you need to run two different products at the same time, separate single-head machines are recommended.

The Mac 200 fills a wide range of products: toothpaste, pharmaceutical creams and ointments, cosmetic gels, sunscreen, hand cream, eye cream, antiseptic cream, shaving gel, hair dye, tooth gel, wound healing gel, foot care cream, and industrial pastes. The dual servo pumps handle viscosities from water-thin liquids to stiff, stringy pastes without product cavitation or dosing error.

Yes. The Mac 200 is designed for pharmaceutical, cosmetic, and personal care production environments. Contact surfaces are 316L stainless steel and the machine supports clean-in-place (CIP) procedures. Dual servo dosing pumps deliver validated, repeatable fill accuracy — a key requirement for regulated pharma lines. IQ/OQ documentation packages are available on request.

The Mac 200 is available in Hot Air (HA) for laminated and plastic tubes, Metal (AL) for aluminium fold-and-crimp tubes, and Combination for lines that run both tube materials. The HA configuration supports decorative trim seals, embossed finishes, and punch holes for hang-sell retail packaging. The AL configuration offers single fold, double fold, saddle fold, and branded crimp styles.

The Mac 200 is designed for tool-free changeovers. Format parts (tube holders, closing dies) on both heads are quick-release and labelled per tube SKU. A typical tube diameter changeover is completed in under 30 minutes by a single operator. Pacmac pre-configures all format sets to your specific tube portfolio before delivery, so changeovers are guided by SKU labels rather than manual measurement.

The Mac 200 discharge conveyor is engineered to link directly with Pacmac Pac Volt, Pac Glide, or Pac Nova cartoners. Standard I/O signals synchronise line speed and reject handling between both machines. Our applications team designs the complete tube filling to cartoning line layout — including conveyor bridging, speed matching, and MES connectivity — during the project phase.

The Mac 200 is designed and manufactured by Pacmac. Every machine is factory acceptance tested (FAT) before shipment. After-sales support includes on-site commissioning, operator and maintenance training, spare parts supply, and remote diagnostics via the HMI Ethernet interface. Pacmac's service team supports customers globally throughout the machine lifecycle.
